WELCOME Mobile Surveillance Solution

Contact Person www.vimtec.e u

VIMTEC - the company • Founded in 1991 • 25 years of experience • Own development MBE • Made in Germany • Customized development Target: High- High-End – autarkic surveillance / monitoring systems www.vimtec.e u

Areas of activity • Construction site safety • Monitoring of police operations • Fire surveillance • Event monitoring – e.g. public viewing • Traffic surveillance – road works • Border surveillance • and more www.vimtec.e u

Trailer www.vimtec.e u

Details Chassis and body • Tandem trailer, gross vehicle weight 2500 kg • l = 4460mm x w = 2070mm x h = 3175mm • Galvanized solid steel base frame • Box body made of sandwich GRP PU foam • 2 lockable double doors at front and 1 lockable upwards opening flap with gas struts at rear Road safety • Admission up to 100km/h • Overrun brake • Axle shock absorbers www.vimtec.e u

Details Indoor • 880 Ah/ 24 V gel cell • Battery controller to monitor and control the power storage system • Cabinet to control all information and network components • PLC to monitor operational status and operation control Status reports • Control of hydraulic, pneumatic and optional lightning • Industrial embedded PC, 2 GHz, 128 GB SSD, Windows 7 Professional 32 – Bit • Temperature status sensors • Battery control display • Tank level display                    www.vimtec.e u

Details Sabotage reliability • Pneumatic telescopic mast with internal cable routing • Intrusion detection system with motion sensor, locking elements and magnet contacts • Hydraulic pillar Hydraulics • 4 internal hydraulic pillars cylinders • Stroke length 600mm • Separately controlled • Hydraulic unit, 1.5 kW, with 10 litre tank and oil filter • Guaranteed stability up to 120km/h wind speed www.vimtec.e u

Details Diesel generator • Up to 120 days self sufficient - 200l fuel tank • 5 kVA power - fuel consumption 0.6 – 1.0 litres per hour • Diesel generator engine management • Powered by a hybrid system Observation technology • The pneumatic mast can take a weight up to 120 kg • Mast – up to 8m • Masthead quick change System • Compatible with different observation technologies • The Masthead includes a VPN router, an un- www.vimtec.e managed switch and u a high performance outdoor antenna

Masthead observation technology Standard – 360° 360 Observation • 4 x 3 megapixel day/night cameras • 360° view around the MBE - radius of 75m • Video analytic detects persons and cars • Alarm triggering is reported • Horizontal field – up to 100° • Observation head is expandable with a 360° illumination         www.vimtec.e u
