EASA AD No.: 2015-0235
Component Part Number Old Part F-28C/F-28C-2/280C
Name (P/N) Number
MTOW = MTOW = MTOW =
2200 lbs 2350 lbs 2600 lbs
Coupling, Tail Rotor 28-13609-1 1 200 FH 1 200 FH 1 200 FH
Driveshaft
Coupling, Flex Pack 28-01041-3 A005-1992 1 200 FH 1 200 FH 1 200 FH
Assembly (Dana)
Tail Rotor Gear set ECD074-1, XR-137-2YL, 1 200 FH 1 200 FH 1 200 FH
ECD074-2 XR-137-2R
Tail Rotor Gear set ECD100-1, 1 200 FH 1 200 FH 1 200 FH
ECD100-2,
ECD100-1A,
ECD100-2A,
ECD100-1B,
ECD100-2B
Tail Rotor Gear set ECD101-1, 1 200 FH 1 200 FH 1 200 FH
ECD101-2
Drag Link 28-14283-1 + + 13 750 FH
Main Rotor Spindle 28-14282-11 19 000 FH 19 000 FH 19 000 FH
Thrust Bearing 28-14320-12, ΔΔ ΔΔ ΔΔ
(Lamiflex) 28-14320-15
Tachometer Drive NAS1611-333 Δ Δ Δ
Belt (O-Ring)
** On Condition when used with grease fitting
+ No Time limit. Remove Component on condition per Maintenance
Manual inspection criteria.
++ Right hand installations only (28-16300); left hand installations are on
condition.
ΔΔ Retire from service 5 calendar years from date of manufacture all Lamiflex
bearings serial number 5997 and prior.
Retire from service 5 calendar years from date of installation* or 8
calendar years from date of manufacture, whichever occurs first, all
Lamiflex bearings serial numbers 5998 and subsequent.
*Note: Date of installation is defined as the date the Lamiflex bearing
packaging is opened.
Δ Retire from service 5 calendar years from date of installation or package
opening, or 8 years from date of manufacture, whichever occurs first.
N/A Not approved for installation.
